Olympus IX73

The IX73 inverted microscope system sets new standards in advanced live cell imaging with its compact frame, outstanding optical performance and exceptional flexibility.

Available as a one-deck system with a low, ergonomic stage or as a two-deck system with additional expansion capabilities. Both provide the ability to perform a multitude of imaging applications.

Olympus IX73
High stability

Compact with robust mechanical and thermal stability. Ideal for time-lapse or other long-term applications.

Modular motorisation

Adaptable automation of fluorescence and transmitted light condensers, filter wheels for illumination and observation light paths, shutters, stages and nosepieces.

Dedicated to Fluorescence

Fluorescence illumination systems and high definition ion coated filters provide the highest signal to noise performance.

System solutions

Imaging software packages enable archiving, analysis of multi-stained specimens, automated experiments, imaging, high content screening and more.

Making the invisible visible

The new optical system reveals previously unseen detail. A high signal to noise ratio and wide spectral wavelength range deliver superb images with low excitation powers.

Microscope frame
Microscope frame
Optical system
Optical system
UIS2 optical system
Revolving nosepiece
Revolving nosepiece
Revolving nosepiece
Focus
Focus
Stroke: 10 mm
Light-path selection
Light-path selection
50:50 (Left-side port: BI port)
Transmitted light illuminator
Transmitted light illuminator
30 W halogen illuminator: detachable condenser lens system (NA 0.3, W.D. 72 mm), single filter holder aperture iris diaphragm adjustable. 100 W halogen illuminator: pillar tilt mechanism (30° inclination angle, with vibration reducing mechanism), Condenser holder (with 88 mm stroke, refocusing mechanism). Field iris diaphragm adjustable, four filter holders.
Observation tube
Observation tube
Wide-field (FN 22)
Wide-field (FN 22)
Wide-field tilting binocular. Wide-field binocular
Stage
Stage
Mechanical stage with right handle
Mechanical stage with right handle
Stage stroke: X: 114 mm x Y: 75 mm, stage position locking function
Gliding stage
Gliding stage
Upper circular stage 360° rotatable, 20 mm (X/Y) travel
Plain stage
Plain stage
232 mm (X) × 240 mm (Y) stage size, stage insert plate exchangeable (ø110 mm)
Condenser
Condenser
Long working distance universal condenser
Long working distance universal condenser
NA 0.55, W.D. 27 mm 5 positions for optical devices (3 positions for ø30 mm and 2 position for ø38 mm)
Long working distance relief contrast
Long working distance relief contrast
NA 0.5, W.D. 45 mm, 4 positions for optical devices (for ø50 mm, relief contrast optical devices rotatable)
Ultra-long working distance
Ultra-long working distance
NA 0.3, W.D. 73.3 mm, 4 positions for optical devices (for ø29 mm)
Fluorescence illuminator
Fluorescence illuminator
Straight design with field iris diaphragm
Fluorescence
Fluorescence
Fluorescence mirror turret
Fluorescence mirror turret
Turret with 8 positions, built-in shutter, simple waterproof structure
Fluorescence light source
Fluorescence light source
130 W Halogen light guide illumination100 W Hg apo lamp housing and transformer100 W Hg lamp housing and transformer75 W Xenon lamp housing and transformer
Operating environment
Operating environment
Indoor use - Ambient temperature: 5º to 40ºC (41º to 104ºF). Maximum relative humidity: 80% for temperatures up to 31ºC (88ºF), decreasing linearly through 70% at 34ºC (93ºF), 60% at 37ºC (99ºF), to 50% relative humidity at 40ºC (104ºF). Supply voltage fluctuations: Not to exceed ±10% of the normal voltage
