In-vivo Manipulator, triple axis

The IVM-3000 motorised micromanipulator was developed in collaboration with leading researchers to create an affordable, stable, versatile, low noise, long travel, stereotaxic micromanipulator.

"Compared to other micromanipulators I have used, the Scientifica IVM allows us to isolate more cells and to record from each cell for a longer time" Dr. Nicholas Lesica, Ear Institute, University College London

>> Read more IVM references

The three axis model features an easy to exchange modular design with acccessories available to mount to a range of stereotaxes, or straight onto your lab table. High quality materials and precision assembly, along with the super smooth motion and long term stability, means that the IVM offers the best choice for the most demanding in vivo applications.

You may also be interested in the single axis varient of this product;

> Single Axis IVM product page

The IVM-3000 motorised micromanipulator was developed in collaboration with leading researchers to create an affordable, stable, versatile, low noise, long travel, stereotaxic micromanipulator.

"Compared to other micromanipulators I have used, the Scientifica IVM allows us to isolate more cells and to record from each cell for a longer time" Dr. Nicholas Lesica, Ear Institute, University College London

>> Read more IVM references

The three axis model features an easy to exchange modular design with acccessories available to mount to a range of stereotaxes, or straight onto your lab table. High quality materials and precision assembly, along with the super smooth motion and long term stability, means that the IVM offers the best choice for the most demanding in vivo applications.

You may also be interested in the single axis varient of this product;

> Single Axis IVM product page

•  Ultra stable - less than 1 micron drift in 2 hours allows long term experiments
•  Low noise electronics - suitable for single channel recordings
•  Super smooth motion - 20nm resolution and quality engineering means you can reliably position your electrode or probe on the cell of choice
•  Long travel - 75mm of travel for thick slice and in-vivo preparations
•  Choice of controls - PatchPad and software controlled for maximal versatility
•  Modular design - easily mounted to stereotaxic equipment
•  Choice of accessories - customise your IVM to suit your experiment

All three axis share dimensions, shown here in mm

For increased versatility, the IVM micromanipulator can be mounted to a variety of different stereotaxic systems, using Scientifica-built brackets and accessories. Speak to one of our sales representatives to discuss any special requirements.

Dovetail Probe Holder - Dove tail probe holder to fit bars/probes

Extended Right Angled Kopf mount - Allows the user to mount the IVM in one of 4 mounting positions on the Kopf or Stoelting manipulator

Right Angled Kopf Mount - Allows the user to mount the IVM in one of 4 mounting positions on the Kopf or Stoelting manipulator

Extended probeholder

> Download the Product Brochure

> Download the IVM  Manual
