Scientifica Multiphoton Galvo System
Scientifica Multiphoton Galvo System
Overview Technical Data

Scientifica Multiphoton Galvo System

Schematics

In vivo, large back aperture - side

In vivo, large back aperture - top

In vivo, large back aperture - front

In Vitro, Large Back Aperture - side

In Vitro, Large Back Aperture - top

In Vitro, Large Back Aperture - front

Standard System

We can customise this system to suit your unique experimental needs. Please contact us to discuss your requirements.

1 x Galvanometer scan head
1 x Detector

MDU, MDU XL, Chromoflex or FLIM

1 x Sofware

Compatible with ScanImage, SciScan or custom software

1 x Launch optics

Transmitted or reflected launch optics as required

Scanning

  • Scanning mirrors: 3 x 5 mm 8315KL scanning mirrors (MicroMax 671HP Drivers)
  • Maximum scan speed: 2 kHz in bidirectional scan mode (4 fps @512x512 px), 1 kHz in unidirectional scanning mode (2 fps @512x512 px)
  • Maximum scan angles (galvo): MP-2000: +/- 10 optical degrees
  • Maximum scan angles (scan head): +/- 7.6 optical degrees
  • Scan Control: SciScan, ScanImage 3.8.1

Beam

  • Beam input height: MP-1000: 198 mm, MP-2000: 280.6 mm
  • Maximum beam input diameter: <3 mm
  • Beam expansion: MP-1000: 3.3X, MP-2000: 6.7X
  • Beam diameter at back aperture: MP-1000: <10 mm, MP-2000: <20.1 mm

Lenses

  • Relay lens expansion: 1x
  • Lens coating: 700-1200 nm (Rav <0.5%)

Mirrors

  • Turning mirror size: MP-1000: 26 x 36 x 3 mm, MP-2000: 45 x 64 x 6 mm
  • Turning mirror coating: Protected silver (98% reflectivity)

Other specs

  • Typical field of view: MP-1000: ~800 µm2 (16x), ~750 µm2 (20x)*, MP-2000: ~300 µm2 (40x)
  • Galvo voltage/optical degree: 0.25 V
